OD 35mm or 43mm 3 arms Roller Centralizer Tool oil and gas production well logging tool

FOB Reference Price:Get Latest Price
US $2,000-40,000 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shandong, China (Mainland)
Brand Name:
CNPS
Model Number:
PRC-3
Product name:
OD 35mm or 43mm 3 arms Roller Centralizer Tool
model:
PRC-3
OD:
35mm or 43mm
Max Temperature:
175℃ (350℉)
Max Pressure:
15000psi (103MPa)
Shipping Length:
583mm (22.95") 709mm (27.91")
Make-up Length:
488mm (19.21") 600mm (23.62")
Weight:
2kg (4.4lbs) 4.1kg (9.02lbs)
Max Pipe Size:
140mm (5.51") 159mm (6.26")
Upper-to-lower Resistance:
<0.5Ω
SupplyAbility
SupplyAbility:
30 Piece/Pieces per Quarter
Packaging & Delivery
Packaging Details
wooden box,paper box for OD 35mm or 43mm 3 arms Roller Centralizer Tool for oil and gas production well logging tool
Port
China port
Lead Time :
Shipped in 30 days after payment

OD 35mm or 43mm 3 arms Roller Centralizer Tool  oil and gas production well logging tool

Product Description



This centralizer is a 3-arm, single-roller version, used to centralize the logging toolstring in vertical, deviated or horizontal wellbore for production logging operations. The tool has three centralizing arms, each equipped with one roller at the elbow section. Each arm is connected on either side with a slick joint, which ensures accurate centralizing of the tool. The tool provides persistent contact force from three sides. The enduring carbide roller prolongs the life of the tool.



Advantages



Reduce straight length of the toolstring to help pass kick-off points
Tool OD can be customized
H2S resistant

Specifications





Parameters:35mm (1 3/8") Version43mm (1 11/16") Version
Max Temperature:175℃ (350℉)
Max Pressure:15000psi (103MPa)
Shipping Length:583mm (22.95″)709mm (27.91″)
Make-up Length:488mm (19.21″)600mm (23.62″)
Weight:2kg (4.4lbs)4.1kg (9.02lbs)
Max Pipe Size:140mm (5.51″)159mm (6.26″)
Upper-to-lower Resistance:<0.5Ω





Certifications



CNPS Petro Equipment Co., Ltd.





Quality Testing

.jpg













Payment&Delivery

Payment (2).jpg

















FAQ

Q1,Could you do OEM Service?

A: Some items accept this service, pls contact us for details.



Q2: What’s your Delivery Time?
A: In generally , the delivery time is about 3-7 days for sample order. We will make the delivery asap with the guaranteed quality.



Q3:What’s the convenient way to pay?
A: Trade Assurance, L/C,T/T,Western Union and Escrow are accepted , and if you have a better idea, please feel free to share with us.


Q4:Which mode of transport would be better?
A: In general , we advice to make delivery by sea for large order, and for small order,Courier,By Air both ok,Also we respect your views of other transportation as well.



Feature Production:

High quality 6 arm Roller Centralizer Tool production well logging toolOD 43mm 1 3 / 8in Jewelled Bearing Continuous Flowmeter production well logging tool35mm 1 3/8in Quartz Pressure Tool well logging toolsOD 35mm FDR - 35 radioactive fluid liquid density meter well logging tools
6 arm Roller Centralizer 2.jpgcfsm3500x350r.jpgQuartz Pressure Tool1.png000001.jpg
